The Story
TMC-7500 Engineered Fluid is a miscible drop in replacement for 3M Novec 7500 offering the same chemistry and physical properties.
TMC-7500 is a clear, colorless, and nonflammable fluid. TMC-7500 is chemically inert and thermally stable. It is a viable option for replacing perfluorocarbons and perfluoropolythers in many industrial applications.
APPLICATIONS
TMC-7500 is intended to replace ozone-depleting and high global warming potential chemicals for the following suggested industrial and electronic applications:
- Cooling fluid for semiconductor and electronic devise manufacture process, testing equipment, and facilities
- Heat transfer fluid
- Direct contact cooling fluid for supercomputers, high voltage transformers, and power electronics
- Cooling fluid, special solvent, and process aid for chemical manufacture process
- Pharmaceutical manufacture process cooling liquid and freezing dry fluid
- Lubricant Deposition
PHYSICAL PROPERTIES
| Form: | Liquid |
| Color: | Colorless |
| Odor: | None |
| Molecular Weight: | 414 g/mol |
| pH: | Not Applicable |
| Liquid Density: | 1.62 g/cm³ (68 °F) |
| Kinematic Viscosity: | 0.8 cSt |
| Boiling Point: | 129°C |
| Melting Point: | -100°C |
| Pour Point: | -100°C |
| Evaporation Rate: | |
| Flash Point: | None |
| Flammability: | Not Applicable |
| Dielectric Strength: | >35 kV |
| Dielectric Constant: | 5.8 @1kHz |
| Vapor Pressure: | 2 kPa (25 °C) |
| Latent Heat of Vaporization: | 88.5 |
| Surface Tension: | No Data Available |
| Water Solubility: | No Data Available |
| Solubility in Water: | No Data Available |
| Ozone Depletion Potential (ODP): | 0 |
| Global Warming Potential (GWP): |
90 |
Not for specification purposes. All values @25°C unless otherwise specified.
PERFORMANCE
Kinematic Viscosity
| Temperature (°C) |
Result (cSt) |
| -60 | 10.95 |
| -50 |
6.121 |
| -40 |
3.897 |
| -30 |
2.681 |
| -20 |
1.98 |
| -10 |
1.69 |
| 0 |
1.38 |
| 10 |
1.08 |
| 20 |
0.85 |
| 30 |
0.72 |
| 40 |
0.64 |
| 50 |
0.56 |
| 60 |
0.49 |
| 70 |
0.44 |
| 80 |
0.41 |
Thermal Conductivity
| Temperature (°C) |
Result (W/m.K) |
| -80 |
0.111 |
| -70 |
0.116 |
| -60 |
0.117 |
| -50 |
0.120 |
| -40 |
0.106 |
| -30 |
0.086 |
| -10 |
0.0733 |
| 0 |
0.0725 |
| 10 |
0.0715 |
| 20 |
0.0701 |
| 30 |
0.0693 |
| 40 |
0.0679 |
| 50 |
0.0668 |
| 60 |
0.0656 |
| 70 |
0.0645 |
| 80 |
0.064 |
MATERIAL COMPATABILITY
TMC-7500 is compatible with most metals, polymers, and plastics.
COMPLIANCE
-
Entry 68 of Regulation (EU) 2021/1297 amending Annex XVII of REACH Regulation (EC) No 1907/2006
- European Regulation POPs (EU) 2020/784 amending Regulation (EU) 2019/1021
SHELF LIFE & STORAGE
Shelf life is 60 months from the date of manufacture when stored in the original packaging materials and stored under normal conditions. TMC will re-certify material every 5 years up to 20 years.
DISPOSAL AND RECYCLING
This fluid can be recycled and reused. Help protect the environment, and don't pay for expensive disposal services. TMC Industries can reclaim your used fluorinated fluids, restoring them to like-new condition, and save you up to 50% in replacement fluids while protecting the environment, or TMC will recycle your fluid free of charge (conditions apply).
TMC Reclaimed Fluids are tested to meet new product specifications. It will be clear and odorless, and a Certificate of Analysis is issued with every order.
TMC Industries offers a 100% satisfaction guarantee on all of our reclaimed fluids. We back this up with a no questions asked refund policy. To learn more, click HERE.
DOCUMENTS
SGS Laboratory Report - TMC-7500 - Non Detectable PFAS
